Tilting drum concrete mixer
Brick block machine

Tilting drum concrete mixer

Author : RuiGuang    Time : 2015-11-16    Click :
Product Description
Tilting Drum Concrete Mixer (with Diesel Engine Power and Hydraulic Tipping Hopper) Loading Capacity 300L, Discharging Capacity 200L, Productivity 6-8 m 3 /h, Drum Rotating Speed 20-22 rpm, Displacement of Gear Pump 25 mL/r, Pressure of Multi-way Valve 16 Mpa, Diesel Engine Brand CHANGCHAI or YANMAR , Diesel Engine Power 12.1 kW or 13.2 kW, Overall Size (L×W×H) 2200×1850×2600 mm, Total Weight 1250 kgs or 1300 kgs
Other Information
Container Loading Plan: 4 Sets Per 20 GP, 8 Sets Per 40HC

Main Technical Parameter
Model RG300
Discharging Capacity 300L
Loading Capacity 500L
Diesel Engine Brand CHANGHAI YANMAR
Diesel Engine Power 12.1KW 13.2KW
Diesel Engine Type Horizontal, single Cylinder, Four-stroked and Water Cooled
Drum Rotating Speed 20-22rpm
Productivity 8-10m 3 /h
Weight 1050KGS
Overall Size(L*W*H) 2200*1850*2600mm
